Stainless Steel Welded Pipes / Tubes
YIETO METAL CO.,LTD is a leading manufacturer & supplier of welded pipe, per ASTM A 312, ASTM A 358 or as rolled and welded. We supply common grades of stainless such as 304/304L and 316/316L in standard pipe sizes and schedules including Sch 5, Sch 10, Sch 40s and Sch 80s. We also supply more challenging stainless welded pipe requirements including 304H, 316H, 309/S, 310/S, 317/L, 321/H, 347/H, 410, 410S, Duplex 2205, Duplex 2507 and many other grades of stainless, duplex or nickel alloys.
We can even supply material with wall thicknesses up to 3″ thick! Diameters sizes range from 1/8″ up to 96″. We specialize in quick delivery of non-standard welded pipe. We recently supplied a steel mill with 3 pieces of 11-1/2″ OD x .625″ Wall x 13’ Type 316/316L and delivered the product in 5 days to meet a shut-down requirement. All welded pipe products can be cut to size. Specialty testing, including X-ray, Hydro Testing and more can be supplied upon request.
Product Description
Stainless Steel Welded Pipes / Tubes
Product Specification and Size :
Available Specification
Product Name | Executive | Dimension | Steel Code / Steel Grade |
Industrial Pipes | ASTM A312, A358, A778 JIS G3459 | OD: 1/4"~40" WT: SCH5S~SCH80S |
TP304, TP304L, TP316L SUS304TP |
Tubes for Boiler and Heat-Exchanger, General Service Tubing | ASTM A249, A269 JIS G3463 | OD: 15.9~139.8mm WT: 1.6~5.0mm |
TP304, TP304L, TP316L SUS304TB |
Mechanical and Structural Tubes | ASTM A554 JIS G3446 | OD: 7.9~152.4mm WT: 0.5~6.5mm |
MT304, MT304L, MT316L, MT430 Grade 201, 202 as per mill's STD SUS304 |
Square Tubes | ASTM A554 | OD: 12.7x12.7~150x150mm WT: 0.7~6.5mm |
MT304, MT304L, MT316L,MT430 Grade 201, 202 as per mill's STD |
Rectangular Tubes | ASTM A554 | OD: 10x20~100x200mm WT: 0.7~6.5mm |
MT304, MT304L, MT316L,MT430 Grade 201, 202 as per mill's STD |
Sanitary Tubing | ASTM A270 JIS G3447 |
OD: 25.4~165.2mm WT: 0.8~3.05mm |
TP304, TP304L, TP316L SUS304TBS |
Large Gauge Pipes for Ordinary Piping | JIS G3448 | OD: 15.88~318.5mm WT: 0.8~3.0mm |
SUS304TPD |
Large Diameter Pipes | JIS G3468 | OD: 14"~40" WT: SCH5S~SCH40S |
SUS304TPY |
Application
Stainless steel pipe (tube) has excellent characteristics of corrosion resistance and smooth finishing. Stainless steel pipe (tube) is commonly used in demanding equipment like automobiles, food processing, water treatment facilities, oil and gas processing, refinery and petrochemicals, breweries and energy industries.
- Automotive industries
- Food processing
- Water treatment facilities
- Breweries and energy industries
